ERS1325J
Eastrise
Features of 1325 1530 Stone Cnc Router
1. Machine bed is welded by the thick wall steel seamless tube, high temperature tempering treatment, high rigidity, bearing strength better .
2. Dual motor drive for Y-axis, moving stably.
3. DSP control with good software compatibility, suitable for Type3, Artcam, JDpaint. RDworks for laser control, professional motion control chip, has the function of consecutively high-speed curve cutting and the shortest path selection, which largely improves your working efficiency.
4. 5.5KW big torque spindle motor, strong carving strength, high efficiency.
5. High precision rack and pinion transmission, fast speed.
6. Imported linear square guide way, double row four row slider, high precision, long life time.
7. Well selected electrical accessory, let the failure rate to the minimum.
8. With water and automatic water supply and cooling system.
9. Dustproof and waterproof design, better to protect the machine driving part.10. Rotary device for option.
Advantage of 1325 1530 Marble Carving Machine
1.Multi-Purpose Stone CNC Machine for Headstone, Memorial Stone, Tombstone in factory
2.Multi-Purpose Stone CNC Machine for Headstone, Memorial Stone, Tombstone Details Show
3.Stone CNC bit + Laser head
4.Stone CNC machine DSP controller
Laser engraving controller
Technical parameters
Model | ERS1325J |
Working size | 1300*2500mm |
Max feeding height | 400mm(Customized) |
Max traveling speed | 40m/min |
Tool diameter | ￠3.175、￠4 、￠6、￠8、￠12.7 |
Transmission | Rack and opinion |
Software environment | WindowsXP/7/8/10 |
Spindle power | 4.5KW/5.5KW(Optional) |
Power without spindle | 2KW |
Voltage | 220V/380V |
Recognizing language | G code（nc）、mmg、plt、eng、dxf |
Spindle speed | 6000-24000rpm/min |
Applications of Multi-Purpose Stone CNC Machine for Tombstone, Headstone, Memorial Stone
Applicable Materials: Headstone, memorial stone, granite tombstone, natural marble, granite, bluestone, sandstone, artificial stone, milestone, ceramic tile, jade, crystal, glass, plastic, wood, bamboo and so on, it can do 3D embossment, line carving, bevelling and laser engraving.
Applicable Industries:
Stone Industry: Headstone, memorial stone, granite tombstone, natural marble, granite, bluestone, sandstone, artificial stone, milestone, ceramic tile, jade, etc.Kitchen Ware Industry: Man-made marble cabinet table surface.
Artwork Decoration Industry: Wood crafts, gift box, jewelry box and other exquisite art crafts.
Mold Industry: Engraving copper, aluminum, and other metal molds; Building models, shoes, badge, embossed mould, biscuit, candy, chocolate mould; Artificial marble, plastic sheeting, PVC, wood, foam and other non-metallic mold.
Advertising Industry: Billboard, signage, badges, logo, company plate, signs, emblem, badge, display panels, fair signs, building numbers, signs of decoration, literal hole cutting etc.; 3D character cutting, acrylic cutting, LED/neon channel, lightbox;The laser head is available for engraving and cutting nonmetal materials, such as acrylic,color plates,ABS board,rubber,plastic,cloth toys,leather ,wool, crystal, glass, ceramic tile, jade, bamboo products, wood products.
Machining
Testing
Certificate
Feedback from customer
After-sales service and guarantee
1) The whole machine has a 3 year warranty, we will provide consumable parts at agent price when you need to replace it.
2) If there is a problem during the warranty period, the main components (except consumables) must be replaced free of charge. The software is being updated for free.
3) Our engineers can provide technical support to your country if necessary.
4) Our engineers can serve at weekends even on holidays.
5) Our engineers can train you at our factory for free.
6) Our engineers can service you online 16 hours a day through Skype, Yahoo, MSN, QQ or mobile.
7) The manual in English and the video on CD for use and maintenance of the machine will be sent to you with the machine.
