Description
1.It is widely used for wood cutting and carving.
2.Vacuum table can hold material fast and stably.
Applicable materails
Soft metal, acrylic,plastic,wood,MDF,PVC and so on.
Standard version main configurations
#3kw water cooling spindle
#NC studio controller
#X Y axis rack and pinion transmission, Z axis Taiwan TBI ball screw transmission
#Vacuum and T-slot table
#Leadshine M860 driver
#NEMA 34 450B stepper motor
#Manual oil lubrication
#Vacuum table
#Taiwan HIWIN 20mm square rails guides
#Fuling inverter
#Tool box
Optional parts
#Rotary axis for round materials engraving and cutting
#Mist cooling system for soft metal engraving and cutting
#Dust collector for wood dust
Technical parameters
Model | ERM1325 |
Working size | 1300*2500mm |
Max feeding height | 200mm(Customized) |
Max traveling speed | 30m/min |
Tool diameter | ¢3.175、¢4 、¢6、¢8、¢12.7 |
Transmission | Rack and pinion |
Software environment | WindowsXP/7/8/10 |
Spindle power | 3KW/4.5KW/5.5KW(Optional) |
Power without spindle | 3KW |
Voltage | 220V/380V |
Recognizing language | G code(nc)、mmg、plt、eng、dxf |
Spindle speed | 6000-24000rpm/min |
Control system | Topwisdom/Mach3 |
Machining
Testing
Certificate
