Introduction to the types and uses of CNC engraving machine tools

Views: 1     Author: Site Editor     Publish Time: 2022-01-04      Origin: Site

As a fully automatic CNC engraving equipment, the engraving machine has become popular in the engraving industry. Many companies have more than one equipment. Larger companies will have 2-3 equipment. However, in the use of equipment, we use What kind of tools do I need to install on the engraving machine?


Today, let us get to know the commonly used tools and types of engraving machines.

cnc engraving machine tools (1)

Double-edged spiral milling cutter, this cutter is mainly used for cutting and milling bottom milling grooves, it is good for MDF, because the cutter diameter is small, the cutting speed cannot be too fast, and it cannot be cut too deep in one cut.

cnc engraving machine tools (7)

The single-edged helical milling cutter has the same function as the double-edged helical milling cutter, except that the single-edged helical milling cutter has a stronger chip removal ability. Suitable for acrylic board, organic board, etc.

cnc engraving machine tools (11)

3.175MM single-edged column cutter: suitable for rough milling or cutting of soft materials, such as wood, PVC, aluminum, etc.

cnc engraving machine tools (4)

Double-edged straight knife: suitable for cutting, grooving, trimming, etc., the chip removal ability is relatively general.

cnc engraving machine tools (6)

Flat-bottomed sharp knife: suitable for fine carving on soft materials, such as embossing, engraving seals, etc.

cnc engraving machine tools (3)

Triangular milling cutter: suitable for engraving on metal surfaces.

cnc engraving machine tools (10)

V-shaped knife, you can open angled V-shaped grooves on the wood board (usually 90 degrees, 120 degrees and 150 degrees, etc.)

cnc engraving machine tools (8)

A three-dimensional knife can cut out the shape of its cross-section on a wooden board.

cnc engraving machine tools (2)

The bottom cleaning knife is mainly used to smooth a large area of the surface. For example, the machine table is milled flat. As the saying goes, this tool is used to mill the table.

cnc engraving machine tools (5)

PCD diamond carving knife flat-bottomed sharp knife, mainly used for granite stone tombstone lettering, sharp and strong wear resistance.

cnc engraving machine tools (9)

Granite cladding knives, carving knives, relief knives, sintered knives, are mainly used for carving reliefs. They are special knives for reliefs and are used at different angles.

cnc engraving machine tools (12)

Mushroom head carving knives, stone carving knives, marble, granite, bluestone, etc. are mainly engraved with large characters, and stone tombstones are mainly engraved with large characters.
