1325 1530 1560 CNC Metal Plasma Cutting Machine for steel, SS, CS, MS

5 0 Reviews
ERP-1530 plasma metal cutting machine is suitable for carbon steel, copper, iron, aluminum and galvanized sheet, titanium sheet,stainless steel and other metal sheet.
Availability:
Quantity:
  • ERP-1530

  • Eastrise

1325 1530 1560 CNC Metal Plasma Cutting Machine for steel, SS, CS, MS

plasma table

Features of Metal Plasma Cutting Machine

1.Heavy machine bed after high temperature treatment can keep running speed and cutting precison.

2.USA Hypertherm and Chinese Huayuan plasma source have good cutting quality and long lifetime.

3.FastCAM or StarCam software with nesting function can save material easily,also convenient to read and process.

4.If cut thick metal,cutting head will have cooling system,which can quickly cool surface of material to avoid burr and smoke.

5.Stepper motor with high precision rack and pinion, to ensure the cnc plasma Machine has small noise,smooth, precise coordinates of the mobile performance.

Advantage of 1325 1530 Plasma Cutter

Automatic THC torch height controller can drive cutting torch go up and down according to material's surface.It can keep the same distance between surface of material and top of torch,because matel sheet is usually not flat.

plasma cutting machine

Emergency stop button for labour security.Our machine has 3 emergency stop buttons,2 are on each side of the gantry and 1 is on control cabinet.

plasma cutting machine (15)

Lubrication system can supply oil to rails.

metal cutting machine

Funnel and drawer can collect waste piece and workpiece easily.

steel cutting machine

Cooling fan will low the temperatue of working motor.

plasma cutter

Application of 1325 1530 1560 Plasma Cutting Machine for metal, steel, SS, CS, MS

Application Material: it is suitable for carbon steel, copper, iron, aluminum and galvanized sheet, titanium sheet,stainless steel and other metal sheet.

Application industry: it is widely used for processing shells of machinery and electronic products, advertising signs, crafts, iron garden, car manufacture, boat building, electrical accessories, board cutting.

plasma cutting

Technical parameters

Specifications

Parameters

Working Area(X Y)

1500*3000mm

Power source

Hypertherm/Huayuan plasma power supply

Cutting Speed

0-16000 mm/min

Plasma Unit Max

5.5KW

Positioning accuracy

±0.3mm

Arc

Untouched arc striking

Software support

FASTCAM plasma software

Instruction format

G code

Working table

Serrate working platform

Working pressure

0.3-0.7Mpa

Working voltage

3Phase 380V/60HZ

Machine dimension(L*W*H)

3000*2520*1540mm

Weight

N./GW: 1500/1700KG

Files transfer

USB interface

Machining

cnc router (1)

Testing

cnc router (3)

Exhibition

laser machine


Certificate

cnc router (4)


Feedback from customer

metal cutting machine
