Features of Plasma And Flame Cutting Machine with Rotation
1. Welded structure of thickening square tube, together with Taiwan imported guide rail to ensure running speed and accuracy.
2. Hypertherm plasma power supply together with high sensitive arc pressure adjuster. Self-adjusting can choose the best distance between plasma gun and working piece automatically to ensure high accuracy cutting.
3. CNC plasma cutting for aluminum, stainless steel use Fangling FX430A controller with TubeMaster software for auto material saving function, large capacity storing function, convenient to read and process.
4. Cutting head with cooling system can quickly cool surface of material to avoid burr and residue.
5. Overall stepper motor with high precision rack and pinion, to ensure the cnc plasma Machine has small noise,smooth, precise coordinates of the mobile performance.
Advantage of Plasma And Flame Cutting Machine with Rotation
>It is 4-axis cutting machine,wihch can cut both round tube and square tube.
>cutting faster, more accurate control, the cutting surface is more smooth, no glitches, no black; cutting holes in high quality
>Stability and reliability for light path system and control system
>Humanizing design, convenient operation
>High performance price ratio, low operating cost
>High cutting efficiency and quality, no noisy. Small heat influence area, cutting seam smooth and no deformation, post treatment is not needed
>High precision stepper motor and driver, ensure the efficiency and accuracy, increasing the stability and reliability greatly
Application of 1325 1530 Plasma And Flame Cutting Machine
Application Material: it is suitable for carbon steel, copper, iron, aluminum and galvanized sheet, titanium sheet,stainless steel and other metal sheet.
Application industry: it is widely used for processing shells of machinery and electronic products, advertising signs, crafts, iron garden, car manufacture, boat building, electrical accessories, board cutting.
Technical parameters
Specifications | Parameters |
Working Area(X Y R) | 1300*2500mm Rotation:diamater 200mm round tube or 200x200mm square tube |
Power source | Hypertherm/Huayuan plasma power supply |
Cutting Speed | 0-16000 mm/min |
Plasma Unit Max | 5.5KW |
Positioning accuracy | ±0.3mm |
Arc | Untouched arc striking |
Software support | TubeMaster plasma software |
Instruction format | G code |
Working table | Serrate working platform |
Working pressure | 0.3-0.7Mpa |
Working voltage | 3Phase 380V/60HZ |
Machine dimension(L*W*H) | 3000*2520*1540mm |
Weight | N./GW: 1500/1700KG |
Files transfer | USB interface |
Machining
Testing
Exhibition
Certificate
Feedback from customer
